Pro pad printing machines

All our machines of Pro pad printing

Advantages of our Pro pad printing machines

Our automatic pad printing machines from the PRO range are high-technology equipment, ideal for industrial applications requiring high-quality printing and great precision. They are designed to offer optimal performance, with features adapted to the specific needs of each production line.

These models are equipped with ink cups that allow for the marking of objects of various diameters and offer the possibility of printing from 1 to 6 colors, depending on the model and chosen configuration, thus providing great flexibility.

The machines also allow for programming cycle counters, automatic pausing for cliché cleaning, and adjusting the pad stroke (from 0 to 100 mm), thereby ensuring maximum flexibility and high productivity.

Additionally, a conveyor system can be integrated to further automate the process, ensuring a continuous workflow and even more efficient production.

Professional automatic pad printing, the key to reliable and precise marking for your industrial products!

Our range of Pro pad printing machines

Machine de tampographie serie 100

TTN Series 100 Automatic Pad Printing Machines

The TTN 100 series automatic pad printing machines are state-of-the-art equipment specifically designed for large-scale series marking. Each mark is produced with high precision, which is essential for long production runs.

They are equipped with an advanced electronic control system featuring an illuminated LCD screen that displays all available functions in real time, meeting a wide range of industrial applications.

The machines offer the ability to program cycle counters, trigger an automatic pause for cliché cleaning, and adjust the pad stroke, thus ensuring optimal flexibility and increased productivity.



View product
Equipement de tampographie TTN 200

TTN 200 Series automatic pad printing machines

The TTN 200 EKO series automatic pad printing machines are high-tech solutions specifically designed for large-scale industrial marking. They offer high printing precision, which is essential for mass production, and ensure consistent quality in every cycle.

Equipped with an advanced electronic control system, these machines feature a bright LCD screen that displays all available functions in real-time, allowing for easy and intuitive management of all printing parameters.

They cater to a wide range of industrial applications, with marking capabilities for objects of various shapes and materials.

Thanks to advanced features such as programmable cycle counters, automatic pause for plate cleaning, and fine-tuning of the pad stroke, this equipment ensures efficient production and consistent quality, even in long production runs.

View product
Tampographie en 6 couleurs TTN 600

TTN Series 350 automatic pad printing machines

TTN 350 series automatic pad printers are high-performance solutions designed to meet the demands of large-scale industrial production. Thanks to their cutting-edge technology, they ensure precise and consistent printing, even for the longest runs.

Equipped with a modern electronic control system, these machines feature a bright LCD screen that displays all functions in real-time. This allows for simple and rapid adjustment of printing parameters to ensure optimal management of each production cycle.

They are perfect for a wide variety of industrial applications, capable of marking objects of all shapes and various materials. They offer great flexibility while guaranteeing impeccable print quality.

Among the many available functions are the ability to program cycles, automate pauses for cliché cleaning, and precisely adjust the pad stroke. These features are essential for improving efficiency while maintaining consistent quality, even on long production runs.

View product
Tampographie industrielle sur mesure

Custom automated pad printing

Thermoflan, in partnership with TTN, brings you cutting-edge expertise in designing and manufacturing fully custom automated pad printing solutions.

Our equipment is built to integrate seamlessly into complex automated systems, including linear conveyors, indexing tables, pick-and-place units, and pre- and post-treatment modules.

We offer complete production line automation, covering every stage of the process—from part feeding to printing, as well as unloading, drying, and packaging.

Our turnkey solutions are fully tailored to your needs, developed according to your detailed specifications to precisely match your requirements.

All our machines comply with current CE standards, ensuring a high level of safety and compliance.

View product

Are you interested in our solutions?

FREE QUOTE

How does a Pro pad printing machine work?

Automatic pad printing machines are fully automated. This means that the inking, transferring, and pad cleaning process can be controlled without manual intervention.

Here are the operating steps for automatic pad printing:

Cliché preparation

  • The cliché (made of steel or photopolymer) is engraved with the design or text to be marked.

Inking

  • When a printing cycle begins, the ceramic ring of the ink cup spreads the ink uniformly over the cliché, removing excess ink and leaving ink only in the engraved areas. Only the areas to be printed will be inked.

Ink transfer

  • A silicone pad picks up the ink from the recessed area of the plate, then presses it onto the object.

Printing on the object

  • The pad, loaded with ink, is then pressed against the object’s surface, reproducing the design or text engraved in the plate. Thanks to its flexibility, it adapts perfectly to the shape of the object, even if it is curved, irregular, or difficult to print. The pressure applied by the machine ensures precise ink transfer, thereby guaranteeing a uniform, high-quality print.

Ink drying

  • After transfer, the ink is dried either by natural evaporation or through a heating tunnel drying system, depending on the material of the object.

Next cycle

  • Once printing is complete, the pad is lifted and returned to its initial position, and the inking and transfer process begins again for each subsequent cycle.

Materials compatible with our Pro pad printing machines

Application examples

Advantages and uses of our Pro pad printing machines

  • ADVANTAGES

    High print quality: faithful reproduction of patterns, text, and logos with high precision. Ink transfer is performed uniformly, even on irregular surfaces, ensuring crisp, high-quality printing in every cycle.

    Marking flexibility: marking from 1 to 6 colors, depending on the model and configuration chosen.

    Adaptability to complex surfaces: the flexibility of the pad allows for printing on curved, concave, convex, or irregular surfaces.

    Automation and efficiency: including inking, transferring, and cleaning, it allows for continuous production with minimal manual intervention. This reduces human error, increases productivity, and lowers operational costs.

    Programming: possibility to program and store different programs (such as speed, pad pressure, etc.), thereby facilitating production changes and print repeatability.

    High production speed: they are capable of performing a large number of print cycles per hour (up to 2200 cycles per hour for certain models), making them particularly suitable for large runs and high-volume production.

    Constant precision and reduction of defects: automation ensures perfect repeatability of prints with constant precision and a significant reduction in marking errors or defects.

    Compatibility with a wide range of materials: they can print on a great variety of materials, such as plastic, metal, glass, rubber, wood, and many others, thus offering a versatile solution for numerous industries.

    Conveyor option: a conveyor system can be integrated into the machine to further automate the production process, facilitating a continuous workflow.

    Reduced maintenance and reliability: they are designed to be robust and reliable, with high-quality components and ease of maintenance.

    Space optimization: compact and flexible, the machines can be easily integrated into various production configurations.

  • APPLICATIONS

    Automotive industry: marking parts and components such as buttons, control panels, grilles, dashboards, mirrors, and plastic or metal parts. Manufacturer logos, serial numbers, or other important information.

    Electronics industry: printing on small surfaces of electronic components such as switches, circuit boards, buttons, and connectors, instructions on control panels, electronic devices, and other small-sized items.

    Promotional and advertising items: personalizing promotional articles such as pens, USB drives, keychains, bottles, mugs, boxes, and other complex-shaped objects.

    Packaging and cosmetics: printing logos, product information, barcodes, ingredients, and designs on cosmetic products such as perfume bottles, cream tubes, and makeup vials.

    Medical industry: marking essential information on medical devices such as serial numbers, expiration dates, and instructions for use.

    Sports accessories and equipment: personalizing accessories such as glasses, watches, bags, clothing, and footwear. Marking sports equipment, such as tennis rackets, protective gear, and balls.

    Musical instruments: printing brand logos, serial numbers, and decorative patterns on instruments such as guitars, drums, pianos, and musical accessories.

    Plastics industry: marking on plastic parts such as buttons, handles, and other small components.

    Manufacturing of industrial machinery and equipment: marking important information on industrial machines and equipment such as serial numbers, safety instructions, and technical details.

  • The PRO range of automatic pad printing machines consists of 3 series:

    TTN 100 series range from 1 to 2 colors:

    TTN90 EKO TE

    TTN120 EKO 2TC

    TTN 200 series range from 1 to 4 colors:

    TTN 200 EKO TE Oval

    TTN 200 EKO 2 TC

    TTN 250 EKO 3 TC

    TTN 300 EKO 3 TC

    TTN 300 EKO 4 TC

    TTN 350 series range from 1 to 6 colors:

    TTN 400 EKO 2 TC Oval

    TTN 400 EKO 4 TC

    TTN 450 EKO 3 TC

    TTN 500 EKO 5 TC

    TTN 600 EKO 4 TC

    TTN 600 EKO 6 TC

    Our automatic pad printing machines can be viewed in our showroom. This space allows you to evaluate their performance, print quality, and adaptability to your specific needs.
